MAGNDATA - Collection of Magnetic Structures

N	(x,y,z)	Seitz notation
1	x,y,z,+1	{ 1 \| 0 }
2	-x+1/2,y,-z+1/2,+1	{ 2₀₁₀ \| 1/2 0 1/2 }
3	-x+1/2,-y,-z,+1	{ -1 \| 1/2 0 0 }
4	x,-y,z+1/2,+1	{ m₀₁₀ \| 0 0 1/2 }
(1/2,1/2,0) + set click here to show and hide
5	x+1/2,y+1/2,z,+1	{ 1 \| 1/2 1/2 0 }
6	-x,y+1/2,-z+1/2,+1	{ 2₀₁₀ \| 0 1/2 1/2 }
7	-x,-y+1/2,-z,+1	{ -1 \| 0 1/2 0 }
8	x+1/2,-y+1/2,z+1/2,+1	{ m₀₁₀ \| 1/2 1/2 1/2 }
(0,1/2,0)' + set click here to show and hide
9	x,y+1/2,z,-1	{ 1' \| 0 1/2 0 }
10	-x+1/2,y+1/2,-z+1/2,-1	{ 2'₀₁₀ \| 1/2 1/2 1/2 }
11	-x+1/2,-y+1/2,-z,-1	{ -1' \| 1/2 1/2 0 }
12	x,-y+1/2,z+1/2,-1	{ m'₀₁₀ \| 0 1/2 1/2 }
(1/2,0,0)' + set click here to show and hide
13	x+1/2,y,z,-1	{ 1' \| 1/2 0 0 }
14	-x,y,-z+1/2,-1	{ 2'₀₁₀ \| 0 0 1/2 }
15	-x,-y,-z,-1	{ -1' \| 0 }
16	x+1/2,-y,z+1/2,-1	{ m'₀₁₀ \| 1/2 0 1/2 }

N	(x,y,z)	Seitz notation
1	x,y,z,+1	1
2	-x,y,-z,+1	2₀₁₀
3	-x,-y,-z,+1	-1
4	x,-y,z,+1	m₀₁₀
1' + set click here to show and hide
5	x,y,z,-1	1'
6	-x,y,-z,-1	2'₀₁₀
7	-x,-y,-z,-1	-1'
8	x,-y,z,-1	m'₀₁₀

Magnetic atoms:

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_y	M_z	\|M\|
V1	V	0.06570	0.00370	0.41090	16	m_x,m_y,m_z	0.47	0.47	0.66
V2	V	0.18545	0.24855	0.09100	16	m_x,m_y,m_z	-0.38	0.98	1.05
V3	V	0.00000	0.25000	0.00000	8	m_x,m_y,m_z	-1.17	0.53	1.28
V4	V	0.25000	0.00000	0.00000	8	m_x,m_y,m_z	1.17	0.53	1.28

Non-magnetic atoms:

Label	Atom type	x	y	z	Multiplicity
O1	O	0.15035	0.07300	0.46200	16
O2	O	0.09280	0.16950	0.02600	16
O3	O	0.04100	0.07550	0.63600	16
O4	O	0.21000	0.17150	0.86200	16
O5	O	0.00000	0.14850	0.25000	8
O6	O	0.25000	0.09250	0.25000	8

[Show all atoms in unit cell and their moment relations]

Positions and magnetic moments of all atoms in unit cell, with magnetic moment relations explicitly given:

Magnetic atoms:

Set of atoms in the unit cell related by symmetry with the magnetic atom V1:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.06570	0.00370	0.41090	m_x,m_y,m_z	0.00000	0.47000	0.47000
2	0.43430	0.00370	0.08910	-m_x,m_y,-m_z	0.00000	0.47000	-0.47000
3	0.43430	0.99630	0.58910	m_x,m_y,m_z	0.00000	0.47000	0.47000
4	0.06570	0.99630	0.91090	-m_x,m_y,-m_z	0.00000	0.47000	-0.47000
(1/2,1/2,0) + set click here to show and hide
5	0.56570	0.50370	0.41090	m_x,m_y,m_z	0.00000	0.47000	0.47000
6	0.93430	0.50370	0.08910	-m_x,m_y,-m_z	0.00000	0.47000	-0.47000
7	0.93430	0.49630	0.58910	m_x,m_y,m_z	0.00000	0.47000	0.47000
8	0.56570	0.49630	0.91090	-m_x,m_y,-m_z	0.00000	0.47000	-0.47000
(0,1/2,0)' + set click here to show and hide
9	0.06570	0.50370	0.41090	-m_x,-m_y,-m_z	0.00000	-0.47000	-0.47000
10	0.43430	0.50370	0.08910	m_x,-m_y,m_z	0.00000	-0.47000	0.47000
11	0.43430	0.49630	0.58910	-m_x,-m_y,-m_z	0.00000	-0.47000	-0.47000
12	0.06570	0.49630	0.91090	m_x,-m_y,m_z	0.00000	-0.47000	0.47000
(1/2,0,0)' + set click here to show and hide
13	0.56570	0.00370	0.41090	-m_x,-m_y,-m_z	0.00000	-0.47000	-0.47000
14	0.93430	0.00370	0.08910	m_x,-m_y,m_z	0.00000	-0.47000	0.47000
15	0.93430	0.99630	0.58910	-m_x,-m_y,-m_z	0.00000	-0.47000	-0.47000
16	0.56570	0.99630	0.91090	m_x,-m_y,m_z	0.00000	-0.47000	0.47000

Set of atoms in the unit cell related by symmetry with the magnetic atom V2:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.18545	0.24855	0.09100	m_x,m_y,m_z	0.00000	-0.38000	0.98000
2	0.31455	0.24855	0.40900	-m_x,m_y,-m_z	0.00000	-0.38000	-0.98000
3	0.31455	0.75145	0.90900	m_x,m_y,m_z	0.00000	-0.38000	0.98000
4	0.18545	0.75145	0.59100	-m_x,m_y,-m_z	0.00000	-0.38000	-0.98000
(1/2,1/2,0) + set click here to show and hide
5	0.68545	0.74855	0.09100	m_x,m_y,m_z	0.00000	-0.38000	0.98000
6	0.81455	0.74855	0.40900	-m_x,m_y,-m_z	0.00000	-0.38000	-0.98000
7	0.81455	0.25145	0.90900	m_x,m_y,m_z	0.00000	-0.38000	0.98000
8	0.68545	0.25145	0.59100	-m_x,m_y,-m_z	0.00000	-0.38000	-0.98000
(0,1/2,0)' + set click here to show and hide
9	0.18545	0.74855	0.09100	-m_x,-m_y,-m_z	0.00000	0.38000	-0.98000
10	0.31455	0.74855	0.40900	m_x,-m_y,m_z	0.00000	0.38000	0.98000
11	0.31455	0.25145	0.90900	-m_x,-m_y,-m_z	0.00000	0.38000	-0.98000
12	0.18545	0.25145	0.59100	m_x,-m_y,m_z	0.00000	0.38000	0.98000
(1/2,0,0)' + set click here to show and hide
13	0.68545	0.24855	0.09100	-m_x,-m_y,-m_z	0.00000	0.38000	-0.98000
14	0.81455	0.24855	0.40900	m_x,-m_y,m_z	0.00000	0.38000	0.98000
15	0.81455	0.75145	0.90900	-m_x,-m_y,-m_z	0.00000	0.38000	-0.98000
16	0.68545	0.75145	0.59100	m_x,-m_y,m_z	0.00000	0.38000	0.98000

Set of atoms in the unit cell related by symmetry with the magnetic atom V3:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.00000	0.25000	0.00000	m_x,m_y,m_z	0.00000	-1.17000	0.53000
2	0.50000	0.25000	0.50000	-m_x,m_y,-m_z	0.00000	-1.17000	-0.53000
(1/2,1/2,0) + set click here to show and hide
3	0.50000	0.75000	0.00000	m_x,m_y,m_z	0.00000	-1.17000	0.53000
4	0.00000	0.75000	0.50000	-m_x,m_y,-m_z	0.00000	-1.17000	-0.53000
(0,1/2,0)' + set click here to show and hide
5	0.00000	0.75000	0.00000	-m_x,-m_y,-m_z	0.00000	1.17000	-0.53000
6	0.50000	0.75000	0.50000	m_x,-m_y,m_z	0.00000	1.17000	0.53000
(1/2,0,0)' + set click here to show and hide
7	0.50000	0.25000	0.00000	-m_x,-m_y,-m_z	0.00000	1.17000	-0.53000
8	0.00000	0.25000	0.50000	m_x,-m_y,m_z	0.00000	1.17000	0.53000

Set of atoms in the unit cell related by symmetry with the magnetic atom V4:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.25000	0.00000	0.00000	m_x,m_y,m_z	0.00000	1.17000	0.53000
2	0.25000	0.00000	0.50000	-m_x,m_y,-m_z	0.00000	1.17000	-0.53000
(1/2,1/2,0) + set click here to show and hide
3	0.75000	0.50000	0.00000	m_x,m_y,m_z	0.00000	1.17000	0.53000
4	0.75000	0.50000	0.50000	-m_x,m_y,-m_z	0.00000	1.17000	-0.53000
(0,1/2,0)' + set click here to show and hide
5	0.25000	0.50000	0.00000	-m_x,-m_y,-m_z	0.00000	-1.17000	-0.53000
6	0.25000	0.50000	0.50000	m_x,-m_y,m_z	0.00000	-1.17000	0.53000
(1/2,0,0)' + set click here to show and hide
7	0.75000	0.00000	0.00000	-m_x,-m_y,-m_z	0.00000	-1.17000	-0.53000
8	0.75000	0.00000	0.50000	m_x,-m_y,m_z	0.00000	-1.17000	0.53000

Non-magnetic atoms:

Set of atoms in the unit cell related by symmetry with the atom O1:

Atom	x	y	z
1	0.15035	0.07300	0.46200
2	0.34965	0.07300	0.03800
3	0.34965	0.92700	0.53800
4	0.15035	0.92700	0.96200
(1/2,1/2,0) + set click here to show and hide
5	0.65035	0.57300	0.46200
6	0.84965	0.57300	0.03800
7	0.84965	0.42700	0.53800
8	0.65035	0.42700	0.96200
(0,1/2,0)' + set click here to show and hide
9	0.15035	0.57300	0.46200
10	0.34965	0.57300	0.03800
11	0.34965	0.42700	0.53800
12	0.15035	0.42700	0.96200
(1/2,0,0)' + set click here to show and hide
13	0.65035	0.07300	0.46200
14	0.84965	0.07300	0.03800
15	0.84965	0.92700	0.53800
16	0.65035	0.92700	0.96200

Set of atoms in the unit cell related by symmetry with the atom O2:

Atom	x	y	z
1	0.09280	0.16950	0.02600
2	0.40720	0.16950	0.47400
3	0.40720	0.83050	0.97400
4	0.09280	0.83050	0.52600
(1/2,1/2,0) + set click here to show and hide
5	0.59280	0.66950	0.02600
6	0.90720	0.66950	0.47400
7	0.90720	0.33050	0.97400
8	0.59280	0.33050	0.52600
(0,1/2,0)' + set click here to show and hide
9	0.09280	0.66950	0.02600
10	0.40720	0.66950	0.47400
11	0.40720	0.33050	0.97400
12	0.09280	0.33050	0.52600
(1/2,0,0)' + set click here to show and hide
13	0.59280	0.16950	0.02600
14	0.90720	0.16950	0.47400
15	0.90720	0.83050	0.97400
16	0.59280	0.83050	0.52600

Set of atoms in the unit cell related by symmetry with the atom O3:

Atom	x	y	z
1	0.04100	0.07550	0.63600
2	0.45900	0.07550	0.86400
3	0.45900	0.92450	0.36400
4	0.04100	0.92450	0.13600
(1/2,1/2,0) + set click here to show and hide
5	0.54100	0.57550	0.63600
6	0.95900	0.57550	0.86400
7	0.95900	0.42450	0.36400
8	0.54100	0.42450	0.13600
(0,1/2,0)' + set click here to show and hide
9	0.04100	0.57550	0.63600
10	0.45900	0.57550	0.86400
11	0.45900	0.42450	0.36400
12	0.04100	0.42450	0.13600
(1/2,0,0)' + set click here to show and hide
13	0.54100	0.07550	0.63600
14	0.95900	0.07550	0.86400
15	0.95900	0.92450	0.36400
16	0.54100	0.92450	0.13600

Set of atoms in the unit cell related by symmetry with the atom O4:

Atom	x	y	z
1	0.21000	0.17150	0.86200
2	0.29000	0.17150	0.63800
3	0.29000	0.82850	0.13800
4	0.21000	0.82850	0.36200
(1/2,1/2,0) + set click here to show and hide
5	0.71000	0.67150	0.86200
6	0.79000	0.67150	0.63800
7	0.79000	0.32850	0.13800
8	0.71000	0.32850	0.36200
(0,1/2,0)' + set click here to show and hide
9	0.21000	0.67150	0.86200
10	0.29000	0.67150	0.63800
11	0.29000	0.32850	0.13800
12	0.21000	0.32850	0.36200
(1/2,0,0)' + set click here to show and hide
13	0.71000	0.17150	0.86200
14	0.79000	0.17150	0.63800
15	0.79000	0.82850	0.13800
16	0.71000	0.82850	0.36200

Set of atoms in the unit cell related by symmetry with the atom O5:

Atom	x	y	z
1	0.00000	0.14850	0.25000
2	0.50000	0.85150	0.75000
(1/2,1/2,0) + set click here to show and hide
3	0.50000	0.64850	0.25000
4	0.00000	0.35150	0.75000
(0,1/2,0)' + set click here to show and hide
5	0.00000	0.64850	0.25000
6	0.50000	0.35150	0.75000
(1/2,0,0)' + set click here to show and hide
7	0.50000	0.14850	0.25000
8	0.00000	0.85150	0.75000

Set of atoms in the unit cell related by symmetry with the atom O6:

Atom	x	y	z
1	0.25000	0.09250	0.25000
2	0.25000	0.90750	0.75000
(1/2,1/2,0) + set click here to show and hide
3	0.75000	0.59250	0.25000
4	0.75000	0.40750	0.75000
(0,1/2,0)' + set click here to show and hide
5	0.25000	0.59250	0.25000
6	0.25000	0.40750	0.75000
(1/2,0,0)' + set click here to show and hide
7	0.75000	0.09250	0.25000
8	0.75000	0.90750	0.75000

[Hide]

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_y	M_z	\|M\|
V1	V	0.06570	0.00370	0.41090	16	m_x,m_y,m_z	0.47	0.47	0.66
V2	V	0.18545	0.24855	0.09100	16	m_x,m_y,m_z	-0.38	0.98	1.05
V3	V	0.00000	0.25000	0.00000	8	m_x,m_y,m_z	-1.17	0.53	1.28
V4	V	0.25000	0.00000	0.00000	8	m_x,m_y,m_z	1.17	0.53	1.28
