MAGNDATA - Collection of Magnetic Structures

N	(x,y,z)	Seitz notation
1	x,y,z,+1	{ 1 \| 0 }
2	-x,y,-z+1/2,+1	{ 2₀₁₀ \| 0 0 1/2 }
3	-x,-y,-z,+1	{ -1 \| 0 }
4	x,-y,z+1/2,+1	{ m₀₁₀ \| 0 0 1/2 }
(1/2,1/2,0) + set click here to show and hide
5	x+1/2,y+1/2,z,+1	{ 1 \| 1/2 1/2 0 }
6	-x+1/2,y+1/2,-z+1/2,+1	{ 2₀₁₀ \| 1/2 1/2 1/2 }
7	-x+1/2,-y+1/2,-z,+1	{ -1 \| 1/2 1/2 0 }
8	x+1/2,-y+1/2,z+1/2,+1	{ m₀₁₀ \| 1/2 1/2 1/2 }

N	(x,y,z)	Seitz notation
1	x,y,z,+1	1
2	-x,y,-z,+1	2₀₁₀
3	-x,-y,-z,+1	-1
4	x,-y,z,+1	m₀₁₀

Magnetic atoms:

Label	Atom type	x	y	z	Occupancy	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Nd1_1	Nd	0.83333	0.25130	0.91667	0.3333	8	m_x,m_y,m_z	0.0	0.0	1.57(12)	1.57
Nd1_2	Nd	0.00000	0.75130	0.25000	0.3333	4	0,m_y,0	0.0	1.57(12)	0.0	1.57
Fe1_1	Fe	0.25000	0.25000	0.00000	1.	4	m_x,m_y,m_z	3.00(5)	0.0	0.0	3.00
Fe1_2	Fe	0.91667	0.25000	0.33333	1.	8	m_x,m_y,m_z	-3.64(3)	0.0	0.0	3.64

Non-magnetic atoms:

Label	Atom type	x	y	z	Occupancy	Multiplicity
Sr1_1	Sr	0.83333	0.25130	0.91667	0.6667	8
Sr1_2	Sr	0.00000	0.75130	0.25000	0.6667	4
O1_1	O	0.33333	0.29600	0.91667	1.	8
O1_2	O	0.00000	0.29600	0.25000	1.	4
O2_1	O	0.42417	0.00000	0.07583	1.	8
O2_2	O	0.09083	0.00000	0.40917	1.	8
O2_3	O	0.75750	0.00000	0.74250	1.	8

[Show all atoms in unit cell and their moment relations]

Positions and magnetic moments of all atoms in unit cell, with magnetic moment relations explicitly given:

Magnetic atoms:

Set of atoms in the unit cell related by symmetry with the magnetic atom Nd1_1:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.83333	0.25130	0.91667	m_x,m_y,m_z	0.00000	0.00000	1.57000
2	0.16667	0.25130	0.58333	-m_x,m_y,-m_z	0.00000	0.00000	-1.57000
3	0.16667	0.74870	0.08333	m_x,m_y,m_z	0.00000	0.00000	1.57000
4	0.83333	0.74870	0.41667	-m_x,m_y,-m_z	0.00000	0.00000	-1.57000
(1/2,1/2,0) + set click here to show and hide
5	0.33333	0.75130	0.91667	m_x,m_y,m_z	0.00000	0.00000	1.57000
6	0.66667	0.75130	0.58333	-m_x,m_y,-m_z	0.00000	0.00000	-1.57000
7	0.66667	0.24870	0.08333	m_x,m_y,m_z	0.00000	0.00000	1.57000
8	0.33333	0.24870	0.41667	-m_x,m_y,-m_z	0.00000	0.00000	-1.57000

Set of atoms in the unit cell related by symmetry with the magnetic atom Nd1_2:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.00000	0.75130	0.25000	0,m_y,0	0.00000	1.57000	0.00000
2	0.00000	0.24870	0.75000	0,m_y,0	0.00000	1.57000	0.00000
(1/2,1/2,0) + set click here to show and hide
3	0.50000	0.25130	0.25000	0,m_y,0	0.00000	1.57000	0.00000
4	0.50000	0.74870	0.75000	0,m_y,0	0.00000	1.57000	0.00000

Set of atoms in the unit cell related by symmetry with the magnetic atom Fe1_1:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.25000	0.25000	0.00000	m_x,m_y,m_z	3.00000	0.00000	0.00000
2	0.75000	0.25000	0.50000	-m_x,m_y,-m_z	-3.00000	0.00000	0.00000
(1/2,1/2,0) + set click here to show and hide
3	0.75000	0.75000	0.00000	m_x,m_y,m_z	3.00000	0.00000	0.00000
4	0.25000	0.75000	0.50000	-m_x,m_y,-m_z	-3.00000	0.00000	0.00000

Set of atoms in the unit cell related by symmetry with the magnetic atom Fe1_2:

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.91667	0.25000	0.33333	m_x,m_y,m_z	-3.64000	0.00000	0.00000
2	0.08333	0.25000	0.16667	-m_x,m_y,-m_z	3.64000	0.00000	0.00000
3	0.08333	0.75000	0.66667	m_x,m_y,m_z	-3.64000	0.00000	0.00000
4	0.91667	0.75000	0.83333	-m_x,m_y,-m_z	3.64000	0.00000	0.00000
(1/2,1/2,0) + set click here to show and hide
5	0.41667	0.75000	0.33333	m_x,m_y,m_z	-3.64000	0.00000	0.00000
6	0.58333	0.75000	0.16667	-m_x,m_y,-m_z	3.64000	0.00000	0.00000
7	0.58333	0.25000	0.66667	m_x,m_y,m_z	-3.64000	0.00000	0.00000
8	0.41667	0.25000	0.83333	-m_x,m_y,-m_z	3.64000	0.00000	0.00000

Non-magnetic atoms:

Set of atoms in the unit cell related by symmetry with the atom Sr1_1:

Atom	x	y	z
1	0.83333	0.25130	0.91667
2	0.16667	0.25130	0.58333
3	0.16667	0.74870	0.08333
4	0.83333	0.74870	0.41667
(1/2,1/2,0) + set click here to show and hide
5	0.33333	0.75130	0.91667
6	0.66667	0.75130	0.58333
7	0.66667	0.24870	0.08333
8	0.33333	0.24870	0.41667

Set of atoms in the unit cell related by symmetry with the atom Sr1_2:

Atom	x	y	z
1	0.00000	0.75130	0.25000
2	0.00000	0.24870	0.75000
(1/2,1/2,0) + set click here to show and hide
3	0.50000	0.25130	0.25000
4	0.50000	0.74870	0.75000

Set of atoms in the unit cell related by symmetry with the atom O1_1:

Atom	x	y	z
1	0.33333	0.29600	0.91667
2	0.66667	0.29600	0.58333
3	0.66667	0.70400	0.08333
4	0.33333	0.70400	0.41667
(1/2,1/2,0) + set click here to show and hide
5	0.83333	0.79600	0.91667
6	0.16667	0.79600	0.58333
7	0.16667	0.20400	0.08333
8	0.83333	0.20400	0.41667

Set of atoms in the unit cell related by symmetry with the atom O1_2:

Atom	x	y	z
1	0.00000	0.29600	0.25000
2	0.00000	0.70400	0.75000
(1/2,1/2,0) + set click here to show and hide
3	0.50000	0.79600	0.25000
4	0.50000	0.20400	0.75000

Set of atoms in the unit cell related by symmetry with the atom O2_1:

Atom	x	y	z
1	0.42417	0.00000	0.07583
2	0.57583	0.00000	0.42417
3	0.57583	0.00000	0.92417
4	0.42417	0.00000	0.57583
(1/2,1/2,0) + set click here to show and hide
5	0.92417	0.50000	0.07583
6	0.07583	0.50000	0.42417
7	0.07583	0.50000	0.92417
8	0.92417	0.50000	0.57583

Set of atoms in the unit cell related by symmetry with the atom O2_2:

Atom	x	y	z
1	0.09083	0.00000	0.40917
2	0.90917	0.00000	0.09083
3	0.90917	0.00000	0.59083
4	0.09083	0.00000	0.90917
(1/2,1/2,0) + set click here to show and hide
5	0.59083	0.50000	0.40917
6	0.40917	0.50000	0.09083
7	0.40917	0.50000	0.59083
8	0.59083	0.50000	0.90917

Set of atoms in the unit cell related by symmetry with the atom O2_3:

Atom	x	y	z
1	0.75750	0.00000	0.74250
2	0.24250	0.00000	0.75750
3	0.24250	0.00000	0.25750
4	0.75750	0.00000	0.24250
(1/2,1/2,0) + set click here to show and hide
5	0.25750	0.50000	0.74250
6	0.74250	0.50000	0.75750
7	0.74250	0.50000	0.25750
8	0.25750	0.50000	0.24250

[Hide]

Label	Atom type	x	y	z	Occupancy	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Nd1_1	Nd	0.83333	0.25130	0.91667	0.3333	8	m_x,m_y,m_z	0.0	0.0	1.57(12)	1.57
Nd1_2	Nd	0.00000	0.75130	0.25000	0.3333	4	0,m_y,0	0.0	1.57(12)	0.0	1.57
Fe1_1	Fe	0.25000	0.25000	0.00000	1.	4	m_x,m_y,m_z	3.00(5)	0.0	0.0	3.00
Fe1_2	Fe	0.91667	0.25000	0.33333	1.	8	m_x,m_y,m_z	-3.64(3)	0.0	0.0	3.64

[Show all magnetic atoms in unit cell and their moment relations]

Positions and magnetic moments of all atoms in unit cell, with magnetic moment relations explicitly given:
