MAGNDATA - Collection of Magnetic Structures

Transformation matrix from the setting of the parent structure (a_p,b_p,c_p) to the working setting (a,b,c):

[Hide]

Symmetry operations of the magnetic space group in the setting used:

[Hide]

Transformation matrix from the working setting (a,b,c) to the standard setting of the magnetic space group (a_s,b_s,c_s):

[Hide]

Symmetry operations of the magnetic point group in the setting used:

[Hide]

Magnetic atoms:

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Tm1	Tm	0.06766	0.25000	0.98180	4	m_x,m_y,m_z	0.54(4)	0.25(1)	-0.54(3)	0.80
Cr1_1	Cr	0.00000	0.00000	0.50000	2	m_x,m_y,m_z	0.22(5)	1.56(5)	1.26(6)	2.02
Cr1_2	Cr	0.50000	0.00000	0.00000	2	m_x,m_y,m_z	-0.22(5)	-1.56(5)	-1.26(6)	2.02

Non-magnetic atoms:

Label	Atom type	x	y	z	Multiplicity
O1	O	0.45300	0.25000	0.11360	4
O2_1	O	0.30190	0.05620	0.69080	4
O2_2	O	0.19810	0.94380	0.19080	4

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.06766	0.25000	0.98180	m_x,m_y,m_z	0.54000	0.25000	-0.54000
2	0.93234	0.75000	0.01820	m_x,m_y,m_z	0.54000	0.25000	-0.54000
3	0.56766	0.25000	0.51820	-m_x,m_y,m_z	-0.54000	0.25000	-0.54000
4	0.43234	0.75000	0.48180	-m_x,m_y,m_z	-0.54000	0.25000	-0.54000

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.00000	0.00000	0.50000	m_x,m_y,m_z	0.22000	1.56000	1.26000
2	0.50000	0.50000	0.00000	-m_x,m_y,m_z	-0.22000	1.56000	1.26000

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.50000	0.00000	0.00000	m_x,m_y,m_z	-0.22000	-1.56000	-1.26000
2	0.00000	0.50000	0.50000	-m_x,m_y,m_z	0.22000	-1.56000	-1.26000

Label	Atom type	x	y	z	Multiplicity	Symmetry constraints on M	M_x	M_y	M_z	\|M\|
Tm1	Tm	0.06766	0.25000	0.98180	4	m_x,m_y,m_z	0.54(4)	0.25(1)	-0.54(3)	0.80
Cr1_1	Cr	0.00000	0.00000	0.50000	2	m_x,m_y,m_z	0.22(5)	1.56(5)	1.26(6)	2.02
Cr1_2	Cr	0.50000	0.00000	0.00000	2	m_x,m_y,m_z	-0.22(5)	-1.56(5)	-1.26(6)	2.02

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.06766	0.25000	0.98180	m_x,m_y,m_z	0.54000	0.25000	-0.54000
2	0.93234	0.75000	0.01820	m_x,m_y,m_z	0.54000	0.25000	-0.54000
3	0.56766	0.25000	0.51820	-m_x,m_y,m_z	-0.54000	0.25000	-0.54000
4	0.43234	0.75000	0.48180	-m_x,m_y,m_z	-0.54000	0.25000	-0.54000

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.00000	0.00000	0.50000	m_x,m_y,m_z	0.22000	1.56000	1.26000
2	0.50000	0.50000	0.00000	-m_x,m_y,m_z	-0.22000	1.56000	1.26000

Atom	x	y	z	Symmetry constraints on M	M_x	M_y	M_z
1	0.50000	0.00000	0.00000	m_x,m_y,m_z	-0.22000	-1.56000	-1.26000
2	0.00000	0.50000	0.50000	-m_x,m_y,m_z	0.22000	-1.56000	-1.26000

MAGNDATA: A Collection of magnetic structures with portable cif-type files
